Bowls Cups Chess Turning Wood Lathe For Craftman

Brand: Unique CNC
Model No.: U-UA5025/9025
Chuck Diameter: 160mm
Max.Turning Diameter: 250mm
Price Range: USD2800-3800 according to different configurations
Lead Time: 5-8 working days
Payment Way: TT, Western Union, Credit Card
HS code: 84659200

Email Us

Wood Lathe for Craftman: Master Bowls, Cups,Chess,Pens,Knobs and Various Wooden Crafts

Designed for woodturners who demand automatic and precision, our craftsman wood lathe empowers you to create various wooden crafts. Whether you’re a hobbyist or professional, its compact size and advanced features make small-project detailing effortless.

Videos of this Craftman Wood Turning Lathe

Bowl Turning as Bowl Turning Wood Lathe

Best Lathe for Wooden Goblets

Mini Lathe For Chess

Main features of the Wood lathe for bowl and cup turning

Space-Saving Design: compact wood lathe for small workshops
G code compatible: the machine reads G code generated by Mastercam, UG, etc.
Auto tools changing automatically
Beginner-Friendly: Easy to operate and learn

Technicial Specifications of the Wooden Craft Turning Lathe

Item	Specification
Model No.	U-UA5025/9025 Craftman Wood Turning Lathe
Control System	CNC Control, Compatible with G-Code
Working Size	Diameter: 3–250 mm Length: 500/900 mm
Chuck Diameter	160 mm
Function	Turning, Hollowing, Drilling, Cutting Off
Tailstock	Included
Transmission	High-precision ballscrews 20 mm linear square guide rails
Driving System	High-torque stepper motors - X-axis: 6 N·m - Y-axis: 4 N·m
Turning Spindle Power	1.5 kW
Machine Total Power	2.2 kW
Spindle Rotate Speed	2,800 RPM
Accuracy	≤0.02 mm
Machine Voltage	AC 220 V / 380 V (Single/Three-phase compatible)
Standard Tools	- Hollowing tool and holder: 1 set - Cut-off cutter: 1 piece - Outer turning tool and holder: 1 set
